Description
TEMPERATURE TRANSMITTER GAGE ROSEMOUNT 644
Input
Dual and single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
- Output Signal
- 4-20 mA /HART® protocol, FOUNDATION™ fieldbus protocol, PROFIBUS® PA protocol
- Housing
- Field mount, DIN A head mount or rail mount
- Display/Interface
- LCD Display or LCD Display with Local Operator Interface (LOI)
- Diagnostics
- Basic diagnostics, Hot Backup™ capability, sensor drift alert, thermocouple degradation, min/max tracking
- Calibration Options
- Transmitter-sensor matching (Callendar-Van Dusen constants), 5-point calibration
- Certifications/Approvals
- SIL 2/3 certified to IEC 61508 by an independent 3rd party, hazardous location, marine type, see full specs for complete list of certifications
Extremely versatile temperature transmitter available in HART®, FOUNDATION™ Fieldbus or PROFIBUS® protocols
Diverse mounting configurations including head, field or rail mount with many enclosure options
LOI option eliminates the need for special configuration tools (i.e. field communicator) for ease-of-use
Transmitter-sensor matching with Callendar-Van Dusen constants reduces total measurement error
Hot Backup™ capability and sensor drift alert with dual sensors ensure measurement integrity
Thermocouple degradation diagnostic monitors thermocouple health to detect degradation before failure
Minimum and maximum temperature tracking observes temperature extremes for easy troubleshooting
Device dashboards provide easy interface for simplified device configuration and diagnostic troubleshooting
