Description
SKU E12685-2
Rosemount 3051L Level Transmitter
Rosemount no. 3051L2FEOFD2 1 AA E5L4M5Q4
The Rosemount 3051L Level Transmitter (3051L2FEOFD21AAE5L4M5Q4) is a trusted level measurement solution. Its innovative design, including direct mounting or a Tuned-System™ assembly, reduces temperature effects and significantly enhances response time compared to traditional installations. Equipped with power advisory diagnostics and a user-friendly Local Operator Interface (LOI), this safety-certified transmitter ensures reliable performance.
Specifications:
- Max. Operating Pressure: Up to 300 psi (20.68 bar)
- Process Temperature Range: Based on fill fluid – Maximum 401°F (205°C), Minimum -157°F (-105°C)
- Communication Protocol: 4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS®, 1-5 V Low Power HART®
- Seal System Type: Direct Mount, Tuned-System
- Transmitter Connection: Welded-Repairable
- Process Connection: Flanged: ANSI/ASME, EN/DIN, JIS
- Process Wetted Material: 316L SST, Alloy C-276, Tantalum
- Diagnostics: Basic Diagnostics, Loop Integrity
- Certifications/Approvals: SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE®, hazardous location; refer to full specs for a comprehensive list of certifications.
